The Cheapest 4G Home Router with 300Mbps Firewall VPN Cat4 4G WiFi Modem LTE 4G CPE Router with Sim Card Slot

SPECIFICATIONS

2.4g wi-fi transmission rate: 300 Mbps

5G Wi-Fi Transmission Rate: None

Antenna: 4 Antennas

Brand: WZ-LAN

Chipset: MT7628KN

Encryption Type: WPA2-PSK,WPA2,WPA3,WPA2-Enterprise,WPA-PSK,WPA,WEP,WPA-Enterprise,WPA2-Personal,WPA-Personal,WPA3-Personal

Flash: 2MB

Interface: 1WAN/LAN+3LAN

Memory: 8MB

Product name: 4G LTE CPE Router

SIM card slot: 1*NANO Sim Card Slot

Support: OEM ODM Customization

Supports WDS: No

Supports WPS: Yes

WAN Ports: 2 x10/100Mbps

WiFi Transmission Standard: 802.11n

Wireless Speed: 2.4GHz 300Mbps

Wireless Technology: 802.11b/g/n 300Mbps MIMO

application: Multi-service

function: FireWall,QoS,VPN,SDK available

lan ports: 1

max. lan data rate: 300Mbps

place of origin: Guangdong, China

private mold: Yes

products status: New

standards and protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n

type: Wireless

wifi supported frequency: 2.4G

wired transfer rate: 10/100Mbps

with modem function: No

Product Description

WL-T-CPE306K is a cost-effective wireless communication product developed based on the demand for 4G network. It has a high WiFi wireless rate of up to 300Mbps, meeting the high-speed, stable, secure, and simple internet access needs for small networks such as offices and homes. It can also be applied in the field of IoT communication, providing users with wireless long-distance data monitoring, collection, and transmission capabilities. It supports access to all networks of 4G and is equipped with 2 10/100M adaptive Ethernet LAN interfaces for internal LAN connection. It also has a 10/100M adaptive Ethernet WAN/LAN conversion interface, which can provide wired broadband access. It can be centrally managed through the TR069 protocol centralized management platform, making it easy to know the device status when deployed on a large scale.

Product Feature
1）MT7628KN Chipset，Main frequency Up to580 MHZ, wireless rate is up to 300Mbps
2）1 * WAN/LAN conversion adaptive Ethernet port 3）2 * LAN adaptive Ethernet port

4）Industrial device design, built-in multiple protections such as static electricity, surge, and electric fast transient groups, easily adaptable to various harsh environments, ensuring long-term stability and reliable operation.

5）Independent wireless routing processing chip and module 4G processing chip, each performing its own
function, dual-channel concurrency, ensuring the stability and usability of the entire system.

6）Supports 4G access for Telecom, Unicom, Mobile, and Broadcasting networks, supporting APN/VPDN connections.

7）Supports router mode, AP mode, and 4G LTE wireless access, flexible networking to adapt to various complex scenarios.

8）Provides 802.11b/g/n WiFi 300M wireless access, paired with high-gain antennas, reaches up to 30 meters in open and unobstructed environments. It also provides 10/100Mbps wired access, with a standby capacity of up to 16 devices.

9）Supports WPA/WPA2, SSID hiding, and blacklist features to effectively protect user data security.

10）Rich status indication lights, status overview, easy-to-read log system, easily monitor the device's operational status. Built-in traffic statistics and traffic assistant functions to keep track of data usage.

11）Built-in quick setup wizard, no professional knowledge required, easy to use 4G LTE access for WiFi internet.

12) Customizable deployment based on the TR069 protocol centralized management platform, constantly aware
of the device's operational status, facilitating large-scale deployments.

13) Continuous product updates, feature and performance optimizations, ensuring adaptability to various
network environments and improving user experience.

14) Support OEM/ODM services

4G Module Frequency Band:

*4G Asian version : LTE-FDD: B1/3/5/8; LTE-TDD: B34/38/39/40/41; WCDMA: B1/5/8; GSM: B3/8

*4G Australian version : LTE-FDD: B1/2/3/4/5/7/8/28/66; LTE-TDD: B40; WCDMA:B1/2/4/5/8; GSM: B2/3/5/8

Specification

Main chipset	MT7628KN
Clock Frequency	580MHz
Memory	8MB
Flash	2MB
Wireless Technology	802.11b/g/n 300Mbps MIMO
Device interface	WAN/LAN conversion *1 10/100Mbps adaptive Ethernet port
		LAN *2 10/100Mbps adaptive Ethernet ports
		Nano SIM card
		DC power supply interface, suitable for power plug with outer diameter of 5.5mm, inner diameter of 2.1mm, and length of over 9.5mm
Button	RESET, press and hold for 5 seconds to restore factory settings
Indicator	PWR、WiFi、LAN1、LAN2、WAN、4G
Antenna	Built-in 2.4GHz 2dBi FBC antenna *2
		External 4G LTE 5dBi adhesive stick antenna *2
Power	DC 12V/1A, positive on the outer side and negative on the inner side.
Operating/Storage Temperature	-10℃～45℃/ -20℃～70℃
Operating/Storage Humidity	5%～95%（Non-condensing）
Size	165*120*42mm（excluding antenna）
Frequency Range	802.11b/g/n:2.4~2.4835GHz
Channel	1、2、3、4、5、6、7、8、9、10、11、12、13
Modulation	802.11b: DSSS (DQPSK, DBPSK, CCK)  802.11g: OFDM (BPSK, QPSK,16-QAM)  802.11n: OFDM (BPSK, QPSK,16-QAM, 64-QAM)
Transmission Rate	11b up 11Mbps,11g up 54Mbps,11n up 300Mbps
Receiver Sensitivity	11b：≤-90±1.5dBm @1Mbps，             ≤-84±1.5dBm @11Mbps  11g：≤-86±1.5dBm @6Mbps，            ≤-69±1.5dBm @54Mbps  11n 20MHz：≤-85±1.5dBm @MCS0，                           ≤-67±1.5dBm @MCS7  11n 40MHz：≤-82±1.5dBm @MCS0，                          ≤-64±1.5dBm @MCS7
Transmit Power	11b: ≥20±1.5dBm@11Mbps  11g: ≥20dBm±1.5dBm@54Mbps  11n: ≥20dBm±1.5dBm@MCS7
Network Standard	LTE FDD/TDD
LTE-FDD	B1/B3/B5/B8(supporting hierarchical reception)
LTE-TDD	B34/B38/B39/B40/B41 (supporting hierarchical reception)
Transmission Rate	LTE FDD: Up 150Mbps(DL)/Up 50Mbps(UL)  LTE TDD: Up 130Mbps(DL)/Up 30Mbps(UL)
Transmit Power	FDD B1: -99dBm (10M) FDD B3: -99dBm (10M)  FDD B5: -100dBm (10M) FDD B8: -100dBm (10M)  TDD B34: -98dBm (10M) TDD B38: -100dBm (10M) TDD B39: -98dBm (10M) TDD B40: -99dBm (10M)  TDD B41: -99dBm (10M)
Working Mode	4G/Router/AP
Number of connected users	16 Peoples
Management	The English web remote management/ Batch management based on the TR069 centralized management platform."
