High-Speed 1200Mbps Dual-Band Home Router External Antennas 2.4G+5.8G Wired WEP Firewall 1000Mbps Ports

SPECIFICATIONS

2.4g wi-fi transmission rate: 300 Mbps

5G Wi-Fi Transmission Rate: None

Antenna: 4* 5dBi Antennas

Brand: WZHL

Chipset: SF19A28 1200Mbps high-performance enterprise chip

Dominant frequency: Dual core four process 12 thread CPU, with main frequency up to 1GHz

Encryption Type: WPA2-PSK,WPA2,WPA3,WPA2-Enterprise,WPA-PSK,WPA,WEP,WPA-Enterprise,WPA2-Personal,WPA-Personal,WPA3-Personal

Flash: 16MB

Interface: 1WAN+3LAN 1000Mbps adaptive network interface

Power supply: DC 12V 1A

RAM: 128MB

Supports WDS: No

Supports WPS: Yes

WAN Ports: 1 x10/100/1000Mbps

WIFI: 802.11 B/g/n/ac

Wi-Fi Supported Frequency: 2.4G+5.8GHz

WiFi Transmission Standard: 802.11ac

Wireless Speed: 1200Mbps

application: ENTERPRISE

function: FireWall,QoS,VPN,SDK available

lan ports: 4

max. lan data rate: 1300Mbps

place of origin: Guangdong, China

products status: New

standards and protocols: Wi-Fi 802.11g,Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac

type: Wireless

wifi supported frequency: 2.4G & 5G

wired transfer rate: 1000Mbps

with modem function: No

Product Description

WL1200S is a new generation high-performance enterprise class dual band 1200M router product that supports HW-NAT and 802.11ac technologies. The forwarding speed of external network NAT can reach 900+Mbps, 5.8G provides the highest access rate of 866.7Mbps, and 2.4G provides the highest access rate of 300Mbps, which can meet the requirements of 64 terminals for high-speed Internet access without wires at the same time. Full gigabit network interface, 2.4G 802.11b/g/n 300Mbps+5.8G 802.11a/n/ac 866.7Mbps wireless access speed. Plug and play, featuring high performance, high gain, high reception sensitivity, high bandwidth, high access number, can not only cover a wider range, but also provide higher wireless transmission performance and stability. It is the best choice for wireless access in high-density environments such as education, government, enterprise office, hospital, conference hall, etc. The WL1200S supports hardware NAT fast forwarding. In combination with software performance optimization, the forwarding rate of the WAN interface in NAT mode can reach 900+Mbps, and the forwarding rate in bridge mode can reach 1Gbps. It can easily cope with high bandwidth access, improve Internet access speed, ensure user investment, and greatly improve the user experience. The WL1200S uses a dual band design and a working mode of 2.4G+5.8G. The 5.8G uses a new generation of WiFi wireless standard - 802.11ac protocol. The maximum connection rate can reach 866.7Mbps; Dual frequency is enabled at the same time, and the ultra fast wireless is up to 1200Mbps. Compared with the traditional 802.11n wireless mode, the throughput is increased by 94.5%, bringing a real ultra gigabit high-speed extreme experience. Support WPS, WPA, WPA2 wireless security access, support SSID hiding, visitor network, wireless black-and-white list, WPS, LAN port isolation, ALG, MAC filtering, IP filtering, NAT settings, and DDOS to effectively protect network security and ensure user network data security at all times.

Hardware&software (support OpenWRT)

Processor	SF19A28 1200Mbps high-performance enterprise chip
Dominant frequency	Dual core CPU, with main frequency up to 1GHz
2.4G WIFI	2.4G: 300Mbps 802.11b/g/n MIMO technology
5.8G WIFI	5.8G: 866.7Mbps 802.11b/g/n MIMO technology
Memory	128MB
Flash Memory	16MB
Network port	4 * 10/100/1000Mbps adaptive network interface, 1WAN+3LAN
Button	1 * Reset button, press and hold for 6 seconds to restart, press and hold for more than 6 seconds to restore factory settings.
		1 * Power button, Power switch of control equipment.
		1 * WPS button, easy interconnection without password.
Power connector	DC 12V 1A，﹤12W
Antenna	Omni-directional 5dbi 2.4G external antenna 2pcs
		Omni-directional 5dbi 5.8G external antenna 2pcs
Work environment	Temperature: - 40 ℃～+55 ℃ (working), - 40 ℃～+70 ℃ (storage) Humidity (non condensing): 5%~90% (working), 5%~95% (storage)
Frequency range	ISM band: 2.400GHz~2.4835GHz                    5.180GHz ~ 5.825GHz
